Diamond Saw Blade Asphalt Cutting“U” Groove Diamond Saw Blade
| Item Number | Outer Diameter (Inches) | Outer Diameter (MM) | Hole Diameter(MM) | Segment Dimension | Segment Number |
|---|
| CF27001 | 9″ | 230 | 20/22.23 | 2.5×10×40 | 16 |
| CF27002 | 10″ | 250 | 22.23/25.4 | 2.5×10×40 | 17/18 |
| CF27003 | 12″ | 300 | 25.4/50 | 2.8×10×40 | 20/21 |
| CF27004 | 14″ | 350 | 25.4/50 | 2.8×10×40 | 24 |
| CF27005 | 16″ | 400 | 25.4/50 | 3.2×10×40 | 28 |
| CF27006 | 18″ | 450 | 25.4/50 | 3.2×10×40 | 32 |
| CF27007 | 20″ | 500 | 25.4/50 | 3.2×10×40 | 36 |
| CF27008 | 22″ | 550 | 25.4/50 | 3.2×10×40 | 38 |
| CF27009 | 24″ | 600 | 25.4/50 | 3.2×10×40 | 42 |
| CF27010 | 26″ | 650 | 25.4/50 | 3.2×10×40 | 44 |
| CF27011 | 28″ | 700 | 25.4/50 | 3.2×10×40 | 45 |
